skew skew
105-165 HP 105-165 HP

105-165 HP

E683 is an EICHER branded in-line 6-cylinder, 4.95-liter engine, with an output-range of 105-156 HP and RPM 1500-2150. Eicher branded engines are designed with world-class technology to deliver superb fuel economy, high reliability and uninterrupted power supply. This Eicher branded engine is the right choice for various marine applications.

105-165 HP

Specifications

  • Engine-ModelE683
  • Output-Range105-165 HP
  • Displacement4.95 Liters
  • RPM1500-2150
  • Emission StandardNot Applicable

Technical SPECIFICATIONs

Field Set Features 105HP -165HP
Technical specifications Rated Speed 1500-2150 RPM
Speed Type Variable/Fixed
Gross Power (HP) 105-165
Emission Standards Emissions Complaint Not Applicable
General Bore 100 mm
Stroke 105 mm
Displacement 4.9 Liters
Aspiration TC/TCI
Rotation from Flywheel End Anti-clockwise
Fuel System Mechanical
Compression Ratio 17:01
Cooling System Liquid
Cycle 4 stroke
Number of Cylinders 6-inline
Specification of lube oil API CI4 Plus -SAE 15W 40
Total Lubricating Capacity 17 Liters
Engine Dimensions Dry Weight 520 kg
Height 913 mm
Length 1152 mm
Width 746 mm
