101 KW
EE494 is an EICHER branded in-line 4-cylinder, 3.8-liter engine, with an output of 101 KW and RPM 2200. Eicher branded engines are designed with world-class technology to deliver superb fuel economy, high reliability and uninterrupted power supply. This Eicher branded engine is the right choice for material handling purposes.
Specifications
- Engine Model494
- Output101 KW
- Displacement3.8 Liters
- RPM2200
- Emission StandardCEV IV
Technical SPECIFICATIONs
| Field Set | Features | 101 KW |
|---|---|---|
| Technical specifications | Rated Speed | 2200 |
| Speed Type | Variable | |
| Gross Power (HP) | 137 | |
| Maximum Output (KW) | 101 | |
| Maximum Torque (Nm) | 500 | |
| Emission Standards | Emissions Complaint | CEV IV / V Ready |
| General | Bore | 100 |
| Stroke | 120 | |
| Displacement | 3.8 | |
| Aspiration | Turbocharged | |
| Rotation from Flywheel End | Anti-clockwise, viewed from flywheel | |
| Fuel System | CRDi | |
| Combustion System | Direct Injection | |
| Firing Order | 1-3-4-2 | |
| Minimum Engine Low Idling Speed | 700+/-50 | |
| Maximum Engine Fly up Speed | 2400+/-50 | |
| Compression Ratio | 17.5:1 | |
| Cooling System | Liquid | |
| Cycle | 4 stroke | |
| Number of Cylinders | 4 | |
| Total Lubricating Capacity ( Litres ) | 14.5 | |
| Starting System (V) | 12/24 | |
| Charging Alternator (V) | 12/24 | |
| Crank shaft power take-off | Yes (Optional) | |
| Power steering | Yes (Optional) | |
| Air Compressor | Yes (Optional) | |
| Engine Dimensions | Height | 857 |
| Length | 997 | |
| Width | 738 |
