E483 is an EICHER branded in-line 4-cylinder, 3.3-liter engine, with an output-range of 38-103 HP and RPM 1500-3000. Eicher branded engines are designed with world-class technology to deliver superb fuel economy, high reliability and uninterrupted power supply. This Eicher branded engine is the right choice for various marine applications.



  • Engine-ModelE483
  • Output-Range38-103 HP
  • Displacement3.3 Liters
  • RPM/Hz1500-3000
  • Emission StandardNot Applicable


Field Set Features 38 HP-103 HP
Technical specifications Rated Speed 1500-3000 RPM
Speed Type Fixed/Variable
Gross Power (HP) 38-103
Emission Standards Emissions Complaint Not Applicable
General Bore 100 mm
Stroke 105mm
Displacement 3.3 litres
Aspiration NA/TC/TCI
Rotation from Flywheel End Anti-clockwise
Fuel System Mechanical
Compression Ratio 17:01
Cooling System Liquid
Cycle 4 stroke
Number of Cylinders 4-inline
Specification of lube oil API CI4 Plus -SAE 15W 40
Total Lubricating Capacity 13 Liters
Engine Dimensions Dry Weight 450 kg
Height 782mm
Length 1078mm
Width 775mm
